3D Printer J3030 Xtreme Mechanical Kit‎‏

3D Printer Mechanical Kit help you to build a 3D printer that can giving you a 30x30x30 working area. Kit contents all mechanical parts that you need to build you 3D printer without motors or electronics.
Availability: In stock
3,700.00 ج.م.‏
Your price: 3,330.00 ج.م.‏
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Main Materials: Aluminum Or Acrylic
Main Color: Silver OR Black
Working Area: 30x30x30

Contents:
Aluminum 3D Printer Frame Kit(45x49x49)
1 V-Slot 20x20 Linear Rail Silver (45cm) (Optional)
6 V-Slot 20x40 Linear Rail Silver (45cm) (Optional)

1 V-Slot 20x20 Linear Rail Black (45cm) (Optional)
6 V-Slot 20x40 Linear Rail Black (45cm) (Optional)
16 M5x35mm High Tensile Socket Head Cap Screws
10 M5x10mm High Tensile Socket Head Cap Screws
2 T Joining Plate (Aluminum) (Optional)
2 T Joining Plate (Acrylic) (Optional)
4 Double T-Nut
2 Triple T-Nut

X and Y V-Slot
2 V-Slot 20x20 Linear Rail Silver (49cm) (Optional)
1 V-Slot 20x20 Linear Rail Silver (45cm) (Optional)
2 V-Slot 20x20 Linear Rail Black (49cm) (Optional)
1 V-Slot 20x20 Linear Rail Black (45cm) (Optional)

J3030 Acrylic Or Aluminum Kit
2 X Axis Right side plates (Aluminum) (Optional)
2 X Axis Right side plates (Acrylic) (Optional)
2 X Axis Left side plate (Aluminum) (Optional)
2 X Axis Left side plate (Acrylic) (Optional)
1 X Axis Gantry Plate (Aluminum) (Optional)
1 X Axis Gantry Plate (Acrylic) (Optional)
1 X Axis Limit switch mount Plate (Aluminum) (Optional)
1 X Axis Limit switch mount Plate (Acrylic) (Optional)
1 Y Axis Build Plate 32cmx32cm (Aluminum)
1 Y Axis Belt Tension and ideler mount (Aluminum) (Optional)
1 Y Axis Belt Tension and ideler mount (Acrylic) (Optional)
1 Y Axis Motor mount (Aluminum) (Optional)
1 Y Axis Motor mount (Acrylic) (Optional)
1 Y Axis Limit switch mount Plate (Aluminum) (Optional)
1 Y Axis Limit switch mount Plate (Acrylic) (Optional)
1 Z Axis Top Plate (Acrylic)
1 Z Motor spacer (Aluminum) (Optional)
1 Z Motor spacer (Acrylic) (Optional)
1 Z Axis optical limit switch mount Plate (Aluminum) (Optional)
1 Z Axis optical limit switch mount Plate (Acrylic) (Optional)

Idler, Pulley and Belt
2 GT2 40 Tooth 8mm Bore Timing Belt Pulley
3 GT2 20 Tooth 5mm Bore Timing Belt Pulley
2 Aluminum Idler Pulley 5mm
2 Rubber Timing Belt Width 6mm
1 Gt2 6mm Closed Loop Timing Belt 2Gt-6(930mm)

Bearing, V-Wheel
17 Xtreme or Solid V Wheel Kit
4 693zz Bearing 3x8x4 Flanged
4 688z Bearing 8x16x5 Flanged

Screws and Nut
9 Eccentric Spacer 6mm
17 Aluminum Spacer 5.1 x 10 x 6mm
2 Lead Screw 40cmx8mm
2 Nut Block for 8mm Metric Acme Lead Screw
7 Double T-Nut
6 T-Nut Hammer Head Fasten 5mm
27 M5 Nylock Nut-100-551
2 Lock Collar 8mm
8 Low Profile Screws M5X10MM
4 Low Profile Screws M5X20MM
2 Low Profile Screws M5X25MM
3 Low Profile Screws M5X30MM
8 Low Profile Screws M5 X 35MM
6 Low Profile Screws M5 X 40MM
6 M5x15mm High Tensile Socket Head Cap Screws
2 M3x30mm High Tensile Socket Countersunk Screws
15 M3x10mm High Tensile Socket Head Screws
10 M3x15mm High Tensile Socket Head Screws
10 M3x20mm High Tensile Socket Head Screws
10 M3x30mm High Tensile Socket Head Screws
25 Light Metal Nut Washer 3mm
25 Light Metal Nut Washer 5mm

Package
1 Plywood 3mm Packing Box
