The Arduino Mega 2560 is a microcontroller board based on the ATmega2560 chip. It has 54 digital input/output pins, 16 analog inputs, 4 UARTs (hardware serial ports), a 16 MHz crystal oscillator, a USB connection, a power jack, an ICSP header, and a reset button. It can be programmed using the Arduino Software (IDE), either online or offline, and supports various communication protocols such as I2C, SPI, and Servo. The board is compatible with many Arduino shields and accessories, and can be used for projects that require more I/O lines, more sketch memory, and more RAM. The board comes with a USB cable that connects to your computer and provides power to the board. The Arduino Mega 2560 is ideal for 3D printers, robotics, IoT, and other advanced applications.
Features:
- 54 digital input/output pins (of which 15 can be used as PWM outputs)
- 16 analog inputs
- 4 UARTs (hardware serial ports)
- A 16 MHz crystal oscillator
- A USB connection
- A power jack
- An ICSP header
- A reset button
- 8KB SRAM, 256KB FLASH, 4KB EEPROM
- Compatible with Arduino IDE and Arduino Web Editor
- Supports I2C, SPI, Servo, and other protocols
- Works with many Arduino shields and accessories
Specifications:
- Microcontroller: ATmega2560
- Operating voltage: 5V
- Input voltage (recommended): 7-12V
- Input voltage (limit): 6-20V
- Digital I/O pins: 54 (of which 15 provide PWM output)
- Analog input pins: 16
- DC current per I/O pin: 20 mA
- DC current for 3.3V pin: 50 mA
- Flash memory: 256 KB of which 8 KB used by bootloader
- SRAM: 8 KB
- EEPROM: 4 KB
- Clock speed: 16 MHz
- USB connector: Type B
- Length: 101.5 mm
- Width: 53.3 mm
- Weight: 37 g
