  4. Control Board Ramps 1.6 for 3D Printer
Control Board Ramps 1.6 for 3D Printer
Control Board Ramps 1.6 for 3D Printer Control Board Ramps 1.6 for 3D Printer Control Board Ramps 1.6 for 3D Printer

Control Board Ramps 1.6 for 3D Printer

RAMPS 1.6 interface board with new, more powerful SMT MOSFET drivers Improved heat dissipation with new heat sink，the PCB has a built-in selection terminal for driving the SPI working mode, and is compatible with STEP/DIR and SPI modes The power supply and hot bed use 30A high-current terminal block, to avoid the situation of burning terminals to a greater extent Added a reset expansion interface, convenient for users to extend the reset button, X, Y, Z, E0, E1 all use parallel dual motor interface, so that the board is suitable for more models Design of plate pin socket can be easily replaced or removed for future design, Changed the silk screen, making the wiring clear at a glance. Using a combination of colored pin headers and mothers, effectively distinguishing each functional interface, both beautiful and practical
Availability: 1 in stock
SKU: A-01-07
Manufacturer part number: ARD-SHD-650016-A-01-07
Old price: 400.00 EGP
300.00 EGP
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Control Board Ramps 1.6 for 3D Printer – Expert Description

The Control Board Ramps 1.6 for 3D Printer is a robust and highly adaptable solution tailored for advanced 3D printing applications. This board is expertly engineered to support seamless expansion, allowing direct integration of LCD interfaces and additional modules with ease.

Key Features:

  • Versatile Expansion Capabilities: Easily extend your board with LCD and other accessories to suit evolving project requirements.
  • Advanced Output Management: Equipped with dedicated MOSFET outputs for heaters and fans, ensuring efficient and safe operation of critical printer components.
  • Precision Temperature Monitoring: Features three independent thermistor interfaces for accurate real-time temperature control.
  • Intuitive Output Feedback: Integrated LED indicator instantly signals heater activity, providing clear and immediate system status updates.
  • Enhanced Safety: The heated bed circuit is protected by dual 11A fuses, delivering superior overcurrent protection for demanding workloads.
  • Dual Z Motor Outputs: Specially designed with two Z-axis motor outputs, making it an excellent fit for Prusa-type 3D printers or similar configurations.
  • Comprehensive Motor Support: Includes five stepper motor outputs for versatile multi-axis control and complex motion requirements.
  • Modular Pin Sockets: Innovative pin socket design enables quick and easy removal or replacement, ensuring adaptability for future upgrades or repairs without soldering.
  • Future-Proof Connectivity: I2C and SPI pins are readily available, facilitating smooth integration with additional modules and enabling extensive system expansion.
  • Premium Gold-Plated Connectors: All connectors are gold-plated, supporting a rated current of up to 3A. This ensures optimal conductivity, minimized signal loss, and a compact form factor for streamlined installation.

This control board is meticulously engineered for reliability, efficiency, and future scalability, making it the preferred choice for enthusiasts and professionals demanding superior performance and upgrade flexibility from their 3D printer electronics.

Keywords: Ramps 1.6, 3D Printer Control Board, Dual Z Motor, 5 Stepper Motor Outputs, LCD Expansion, MOSFET Heater, 11A Bed Fuse, Gold-Plated Connectors, I2C, SPI, Thermistor Interface, Modular Pin Socket, Prusa-Compatible, Advanced 3D Printing.
