V-Slot 20x40 Linear Actuator Bundle
Linear Rail Sizes
1 V-slot 20x40 Linear Rail Silver 250mm (Optional)
1 V-slot 20x40 Linear Rail Silver 500mm (Optional)
1 V-slot 20x40 Linear Rail Silver 1000mm (Optional)
1 V-slot 20x40 Linear Rail Silver 1500mm (Optional)
1 V-slot 20x40 Linear Rail Black 250mm (Optional)
1 V-slot 20x40 Linear Rail Black 500mm (Optional)
1 V-slot 20x40 Linear Rail Black 1000mm (Optional)
1 V-slot 20x40 Linear Rail Black 1500mm (Optional)
Motor Type
1 Nema 17 Stepper Motor (Used) (Optional)
1 Nema 17 Stepper Motor (New) (Optional)
Motion System
4 Solid V-Wheel Or Xtreme V-Wheel With (V-Slot Gantry Plate - 20mm) (Optional)
4 Mini V-Wheel With (Mini V Gantry Plate) (Optional)
8 M5X8MM Low Profile Screws (Mini V Gantry Plate) (Optional)
4 M5X8MM Low Profile Screws (V-Slot Gantry Plate - 20mm) (Optional)
1 M5X30MM Low Profile Screws
2 Aluminum Spacer 5.1 X 10 X 6MM With (Mini V Gantry Plate) (Optional)
4 Aluminum Spacer 5.1 X 10 X 1MM With (Mini V Gantry Plate) (Optional)
8 Double T-Nut (Mini V Gantry Plate) (Optional)
2 Double T-Nut (V-Slot Gantry Plate - 20mm) (Optional)
1 GT2 20 Tooth 5mm Bore Pulley
2 Eccentric Spacer 6mm
4 M3x8mm Screws (V-Slot Gantry Plate - 20mm) (Optional)
4 M3x25mm Screws (Mini V Gantry Plate) (Optional)
1 GT2 5mm Bore Idler
2 Nylock Nut 5mm Stainless Steel With (V-Slot Gantry Plate - 20mm) (Optional)
5 Nylock Nut 5mm Stainless Steel With (Mini V Gantry Plate) (Optional)
Belt Size With 20x40 V-Slot
1 Gt2 Rubber Timing 510mm Belt Width 6mm = V-slot 20x40 250mm + Idler Pulley Plate + Nema 17 Motor Mount (Optional)
1 Gt2 Rubber Timing 1100mm Belt Width 6mm = V-slot 20x40 500mm + Idler Pulley Plate + Nema 17 Motor Mount (Optional)
1 Gt2 Rubber Timing 2100mm Belt Width 6mm = V-slot 20x40 1000mm + Idler Pulley Plate + Nema 17 Motor Mount (Optional)
1 Gt2 Rubber Timing 3100mm Belt Width 6mm = V-slot 20x40 1500mm + Idler Pulley Plate + Nema 17 Motor Mount (Optional)
1 Gt2 Rubber Timing 350mm Belt Width 6mm = V-slot 20x40 250mm + Linear Actuator End Mount (Optional)
1 Gt2 Rubber Timing 600mm Belt Width 6mm = V-slot 20x40 500mm + Linear Actuator End Mount (Optional)
1 Gt2 Rubber Timing 1100mm Belt Width 6mm = V-slot 20x40 1000mm + Linear Actuator End Mount (Optional)
1 Gt2 Rubber Timing 1600mm Belt Width 6mm = V-slot 20x40 1500mm + Linear Actuator End Mount (Optional)
Plates Type
1 V-Slot Gantry Plate - 20mm (Acrylic)
1 V-Slot Gantry Plate - 20mm (Steel)
1 V-Slot Gantry Plate - 20mm (Aluminum)
1 Mini V Gantry Plate (Acrylic)
1 Mini V Gantry Plate (Steel)
1 Mini V Gantry Plate (Aluminum)
1 Idler Pulley Plate (Acrylic) With (V-Slot Gantry Plate - 20mm) (Optional)
1 Idler Pulley Plate (Steel) With (V-Slot Gantry Plate - 20mm) (Optional)
1 Idler Pulley Plate (Aluminum) With (V-Slot Gantry Plate - 20mm) (Optional)
1 Nema 17 Motor Mount (Acrylic) With (V-Slot Gantry Plate - 20mm) (Optional)
1 Nema 17 Motor Mount (Steel) With (V-Slot Gantry Plate - 20mm) (Optional)
1 Nema 17 Motor Mount (Aluminum) With (V-Slot Gantry Plate - 20mm) (Optional)
2 Linear Actuator End Mount (Steel) With (Mini V Gantry Plate (Acrylic)) (Optional)
2 Linear Actuator End Mount (Steel) With (Mini V Gantry Plate(Steel)) (Optional)
2 Linear Actuator End Mount (Aluminum) With (Mini V Gantry Plate (Aluminum)) (Optional)
