POS10L is a metric male rod end bearing with a left hand thread. Rod end bearings, also known as heim joints or spherical rod ends, are articulating joints that are attached to the ends of tie rods, steering links, and cylinders to provide a transfer of motion and force between two points. This model is a highly rigid rod end that is basically the same as the female threaded model PHS, but has a male thread on the holder end.
Features:
- The body material is S35C (chromate treatment), which is a medium carbon steel with good strength and machinability.
- The ball material is 52100 steel, which is a high carbon chromium bearing steel with excellent hardness and wear resistance.
- The liner material is a special copper alloy, which has a low coefficient of friction and a high load capacity.
- The bearing has been pre-lubricated with light oil, ensuring that it is ready for immediate use upon delivery.
- The bearing can operate in a temperature range of -20°C to 80°C.
Specifications:
- Bore size: 10mm
- Outer diameter: 26mm
- Overall height: 61mm
- Base to center height: 48mm
- Thread size: M10x1.5
- Thread direction: Left hand
- Allowable incline angle: 8°
- Static load: 2,990 lbf
- Dynamic load: 2,205 lbf
