Omron Press 4-Pin (12×12) (1 PCS)
Omron Press 4-Pin (12×12) (1 PCS) Omron Press 4-Pin (12×12) (1 PCS)

Omron Press 4-Pin (12×12) (1 PCS)

Omron Press 4-Pin (12×12), B3F Tactile Switch Stainless Steel cover Stainless Steel contacts with silver cladding Wave soldering 260?C 10 seconds. Max. Operating temperature range -40?C to +85?C
Availability: 120 in stock
SKU: A-03-105
10.80 EGP
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Omron Press 4-Pin (12×12), B3F Tactile Switch

Stainless Steel cover
Stainless Steel contacts with silver cladding
Wave soldering 260?C 10 seconds. Max.
Operating temperature range -40?C to +85?C

Specifications:

AttributeValue
Contact ConfigurationSingle Pole Single Throw (SPST)
Terminal TypeSolder, Through Hole
Switch OperationMomentary
Actuator Length3.8mm
Actuator ColourPink
Actuator TypeButton
Length12.5mm
Width12mm
Dimensions12 x 12.5mm
Mounting TypeThrough Hole
Contact Current Rating50 mA @ 12 V dc
Height7.3mm
Voltage Rating12V dc
Operating Force360 g
Contact MaterialSilver Plated Stainless Steel
Maximum Operating Temperature+85?C
Operating Temperature Range-40 ? +85?C
Minimum Operating Temperature-40?C
Mechanical Life200000Cycles


Product Datasheet:
