A Nema 23 Stepper Motor Vibration Damper is a device that reduces the noise and vibration caused by the stepper motor. It is designed to fit Nema 23 stepper motors, which are commonly used in CNC machines, 3D printers, and other applications that require precise and smooth motion control. The vibration damper consists of two metal plates and a rubber layer that absorbs the shock and dampens the oscillation of the motor shaft. The vibration damper is attached to the motor using a set screw and can be mounted on any surface. By using a vibration damper, the stepper motor can achieve smoother motion, lower noise, and longer life span.
Features:
- Compatible with Nema 23 stepper motors
- Made of high-quality metal and rubber materials
- Easy to install and use
- Effective in reducing noise and vibration
- Improves motor performance and durability
Specifications:
- Material: Steel and rubber
- Inertia: 0.36 oz/in^2 | 65.84 gm-cm^2
- Mounting: Set screw (M4)
- Shaft size: 0.250" (6.35mm)
- Dimensions: 50 x 50 x 6 mm
- Weight: 75 g
