A load cell 5kg (weight sensor - strain gauge) is a type of electronic sensor that can measure the amount of force or pressure applied to a metal bar. The load cell consists of a flexible backing with a metallic foil pattern, which changes its electrical resistance when it is deformed by the applied force. The change in resistance is proportional to the strain, which is related to the weight of the object on the load cell. The load cell can translate up to 5kg of pressure into an electrical signal, which can be read by a microcontroller or an analog-to-digital converter (ADC). The load cell can be used for various applications, such as weighing scales, industrial automation, robotics, and biomedical devices.
Features:
- High sensitivity and accuracy: The load cell can detect small changes in weight and provide precise measurements.
- Stable and durable: The load cell is made of strong aluminum and epoxy, which protect the strain gauge from damage and environmental factors.
- Easy to use: The load cell has four wires that can be connected to a power supply and an ADC. It also has mounting holes for easy installation.
Specifications:
- Model: YZC-131
- Capacity: 5kg
- Output sensitivity: 1.0 ± 0.15mV/V
- Non-linearity: 0.05% F.S
- Hysteresis: 0.05% F.S
- Repeatability: 0.05% F.S
- Creep: 0.05% F.S/30min
- Zero balance: ±0.1mV/V
- Input resistance: 1000 ± 50Ω
- Output resistance: 1000 ± 50Ω
- Insulation resistance: ≥2000MΩ
- Operating temperature: -20°C to +65°C
- Excitation voltage: 3V to 12V DC
- Dimensions: 75mm x 12.7mm x 12.7mm
