J3030 PCB Machine Full Kit

PCB milling has advantages for both prototyping and some special PCB designs. Probably the biggest benefit is that one doesn't have to use chemicals to produce PCBs. When creating a prototype, outsourcing a board takes time. Alternative is to make a PCB in-house. Using the wet process, in-house production presents problems with chemicals and disposing thereof. High-resolution boards using the wet process are hard to achieve and still, when done, one still has to drill and eventually cut out the PCB from the base material. CNC machine prototyping can provide a fast-turnaround board production process without the need for wet processing. If a CNC machine is already used for drilling, this single machine could carry out both parts of the process, drilling and milling. A CNC machine is used to process drilling, milling and cutting.
Availability: In stock
9,100.00 ج.م.‏
Your price: 8,190.00 ج.م.‏
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

J3030 PCB Machine Full Kit

 Main Materials: Aluminum
 Main Color: Silver OR Black
 Working Area: 30x30

 Contents:

 Aluminum Frame Kit(45x49x49)
1 V-Slot 20x20 Linear Rail Silver (45cm) (Optional)
4 V-Slot 20x40 Linear Rail Silver (45cm) (Optional)
2 V-Slot 20x40 Linear Rail Silver (35cm) (Optional)
1 V-Slot 20x20 Linear Rail Black (45cm) (Optional)
4 V-Slot 20x40 Linear Rail Black (45cm) (Optional)
2 V-Slot 20x40 Linear Rail Black (45cm) (Optional)
16 M5x35mm High Tensile Socket Head Cap Screws
10 M5x10mm High Tensile Socket Head Cap Screws
2 T Joining Plate (Aluminum)
4 Double T-Nut
2 Triple T-Nut

 X and Y V-Slot
2 V-Slot 20x20 Linear Rail Silver (49cm) (Optional)
1 V-Slot 20x20 Linear Rail Silver (45cm) (Optional)
2 V-Slot 20x20 Linear Rail Black (49cm) (Optional)
1 V-Slot 20x20 Linear Rail Black (45cm) (Optional)

 J3030 PCB Aluminum Kit
2 X Axis Right side plates (Aluminum)
2 X Axis Left side plate (Aluminum)
1 X Axis Gantry Plate (Aluminum)
1 X Axis Limit switch mount Plate (Aluminum)
1 Y Axis Build Plate 32cmx32cm (Aluminum)
1 Y Axis Belt Tension and idler mount (Aluminum)
1 Y Axis Motor mount (Aluminum) (Optional)
1 Y Axis Limit switch mount Plate (Aluminum)
1 Z Axis Top Plate 10mm (Acrylic)
1 Z Motor spacer (Aluminum)
1 Z Axis optical limit switch mount Plate (Aluminum)

 Idler, Pulley and Belt
2 GT2 40 Tooth 8mm Bore Pulley
3 GT2 20 Tooth 5mm Bore Pulley
2 Aluminum Idler Pulley 5mm
2 Rubber Timing Belt Width 6mm
1 Gt2 6mm Closed Loop Timing Belt 2Gt-6 (930mm)

 Bearing, V-Wheel
17 Xtreme or Solid V Wheel Kit
4 693zz Bearing 3x8x4 Flanged
4 F688z Flanged Bearing 8x16x5

 Screws & Nut
9 Eccentric Spacer 6mm
2 Lead Screw 40cmx8mm
2 Nut Block for 8mm Metric
7 Double T-Nut
6 T-Nut Hammer Head Fasten 5mm
27 M5 Nylon Lock Nut
2 Lock Collar 8mm
8 Low Profile Screws M5X10MM
4 Low Profile Screws M5X20MM
2 Low Profile Screws M5X25MM
3 Low Profile Screws M5X30MM
8 Low Profile Screws M5 X 35MM
6 Low Profile Screws M5 X 40MM
6 M5x15mm High Tensile Socket Head Cap Screws
15 M3x10mm High Tensile Socket Head Screws
10 M3x15mm High Tensile Socket Head Screws
10 M3x20mm High Tensile Socket Head Screws
10 M3x30mm High Tensile Socket Head Screws
25 Light Metal Nut Washer 3mm
25 Light Metal Nut Washer 5mm
25 Iron Nut 3mm

 Electronics
1 Arduino Mega 2560
1 Ramps 1.4 , 1.5 , 1.6
4 A4988 – Stepper Motor Driver (Optional)
4 DRV-8825 Stepper Motor Driver (Optional)
2 Limit Switch (MS.2 - 19.5 x 10.0 x 6.0 mm)
1 LCD20x4 LCD 2004 interface with SD

 Bed
1 Plywood 6mm Metric Surface 300x300mm (Optional)
1 Aluminum 6mm 7075  Metric Surface 300x300mm (Optional)

 Motors
3 Nema 17 Used motors (Optional)
3 New Nema 17 Motor 48mm (Optional)
1 DC motor 775 12V

 PowerSupply
1 SMPS Power supply 12V

 ControlBox
1 Large Control Box Kit For 3D Printer
1 AC POWER CONNECTOR WITH FUSE HOLDER AND SWITCH
2 12vdc fan 40x40


 Cables
3 4PIN To 6PIN 1m Long Cable For Nema 17 Motor
1 Extension Sensors Cable 70cm
3 4PIN To 6PIN 1m Long Cable For Nema 17 Motor (Without Socket)
1 Arduino Mega USB Cable
1 Power Cable 2M


 Printed Parts
1 Spindle Mount For Motor 775
