This emergency push button is a 22mm device that can be used to stop a machine or a process in case of an emergency. It has a red mushroom-shaped button that can be pressed to cut off the power or signal. It has four terminals that can be wired to two switching circuits: one normally open and one normally closed. It can handle up to 600V and 10A of current and voltage. It can be mounted on a panel with a 22mm cut out diameter. It meets multiple industry safety standards for emergency stops, such as IEC 60947-5, ISO 13850, IEC 60204, and NFPA 79.
Features and specifications:
- Red mushroom-shaped button that can be easily pressed in an emergency
- Four terminals that can be wired to two switching circuits: one normally open and one normally closed
- 600V and 10A rating that can handle high current and voltage
- 22mm cut out diameter that fits most panels
- Multiple industry safety standards for emergency stops, such as IEC 60947-5, ISO 13850, IEC 60204, and NFPA 79
