The DC Motor 370-CF is a high-performance 12V motor, offering a speed of 280 RPM. It is designed for precision and efficiency, suitable for a wide range of applications requiring reliable motion control.
Features:
- High torque output
- Integrated magnetic encoder
- Durable construction
- Low noise operation
Specifications:
- Nominal Voltage: 12 VDC
- Speed: 280 RPM
- Shaft Diameter: 4 mm
- Length: 12 mm
- Connection Wire Length: 20 cm
- No-Load Speed: 100RPM @ 0.13A
- Max Efficiency: 1 Kg.cm/80 RPM @ 0.5A
- Max Power: 3 Kg.cm/55 RPM @ 1A
- Stall Torque: 6.5 Kg.cm @ 3A
- Reduction Ratio: 1:75
- Hall Effect Sensor Resolution: 823.1 PPR1
