0.9V ~ 5V TO 5V 600mA USB Output Charger Step Up Power Module – MINI DC-DC boost Converter
Specification
Size: 24x18mm
Output Current: Rated 0.6A
Type: DC/DC Converters
Input Voltage: 0.9 to 5 Vdc
Output Voltage: 5.1-5.2 Vdc
Weight: 0.03g
Efficiency: Up to 96%
Switching frequency: 500KHz
Voltage indication: LED lights with load
Operating Temperature: Industrial (-40 deg C to +85 deg C)
Output: USB Output
Product Description
Module Properties: non-isolated step-up module (BOOST)
Output Current: Rated 1A-1.5A (single lithium input), the maximum 1.5A (single lithium input)
Voltage indication: LED lights with load (input voltage less than 2.7V LED indicator off)
Full load temperature rise: 30 deg C
Quiescent Current: 130uA
Short circuit protection: None (Please use the lithium battery with protection.)
Input Reverse Polarity Protection: None
Connection: Welding
Input: IN + Postive, IN-Negative – Output: USB Output
