End Mount For Original C-Beam 10mm (Acrylic)

Interchangeable mount allows for easy attachment of a motor to C-Beam Linear Rail. Includes bearing recess typically used in lead screw transmission. Additional countersunk holes for flush mounts make this plate a great choice for your project. Product Features C-Beam Linear Rail compatible Pre-tapped holes Countersunk holes What is Included (1) C-Beam End Mount Product Specifications Size: 80 x 50mm Thickness: 10mm Material: Acrylic Finish: Brushed and Anodized Color: Black

Be the first to review this product

Availability: 1 in stock

SKU: 06.04.05

51.00 ج.م.‏

Qty:

Interchangeable mount allows for easy attachment of a motor to C-Beam Linear Rail. Includes bearing recess typically used in lead screw transmission. Additional countersunk holes for flush mounts make this plate a great choice for your project.
Product Features
C-Beam Linear Rail compatible
Pre-tapped holes
Countersunk holes
What is Included
(1) C-Beam End Mount
Product Specifications
Size: 80 x 50mm
Thickness: 10mm
Material: Acrylic
Finish: Brushed and Anodized
Color: Black
