The Bearing 6303 2Rs is a high-quality deep groove ball bearing designed for a wide range of applications. Its robust design ensures low friction and high-speed capability, making it suitable for both radial and axial loads. The bearing is easy to mount and requires little maintenance, making it a reliable choice for various mechanical assemblies.
Features:
- Versatile Design: Suitable for a multitude of applications.
- Low Friction: Optimized to reduce resistance and wear.
- High-Speed Capability: Enables the bearing to operate at high rotational speeds.
- Radial and Axial Load Accommodation: Can handle loads from all directions.
- Minimal Maintenance: Designed to be durable and long-lasting with little upkeep.
Specifications:
- Bore Diameter: 17 mm
- Outside Diameter: 47 mm
- Width: 14 mm
- Basic Dynamic Load Rating: 14.3 kN
- Basic Static Load Rating: 6.55 kN
- Reference Speed: 34,000 r/min
- Limiting Speed: 22,000 r/min
- Material: Bearing steel (Standard version) or Stainless steel (W 6303-2RS1 variant)
- Sealing: Seal on both sides for the W 6303-2RS1 variant
- Cage: Sheet metal
- Radial Internal Clearance: CN
- Tolerance Class: Class P6 (Standard version) or Normal (W 6303-2RS1 variant)
This bearing is an excellent choice for applications requiring a reliable and robust bearing solution.
