The Bearing 6209 z BW is a high-performance deep groove ball bearing with a cylindrical bore and a single non-contact shield (Z). It is designed to accommodate both radial and axial loads, offering a simple yet robust design that requires minimal maintenance. This bearing is particularly noted for its low friction and the ability to operate at high speeds, making it a reliable choice for a wide range of mechanical applications.
Features:
- Versatile Design: Suitable for a variety of applications due to its simple and robust construction.
- Low Friction: Optimized to reduce resistance and enable smoother operation.
- High-Speed Capability: Can sustain high rotational speeds thanks to its design and low vibration.
- Radial and Axial Load Support: Capable of handling loads from all directions.
- Minimal Maintenance: Designed to require less upkeep, saving time and resources.
Specifications:
- Bore Diameter: 45 mm
- Outside Diameter: 85 mm
- Width: 19 mm
- Basic Dynamic Load Rating: 35.1 kN
- Basic Static Load Rating: 21.6 kN
- Reference Speed: 17,000 r/min
- Limiting Speed: 11,000 r/min
- Sealing: Shield on one side (Z)
- Radial Internal Clearance: CN
- Tolerance Class: P6 (ISO Class 6)
