Main Materials: Aluminum Or Acrylic
Main Color: Silver OR Black
Working Area: 40x40x40
Contents:
3D Printer Aluminum Frame Kit(45x49x49)
1 V-Slot 20x20 Linear Rail Silver (55cm) (Optional)
6 V-Slot 20x40 Linear Rail Silver (55cm) (Optional)
1 V-Slot 20x20 Linear Rail Black (55cm) (Optional)
6 V-Slot 20x40 Linear Rail Black (55cm) (Optional)
16 M5x35mm High Tensile Socket Head Cap Screws
10 M5x10mm High Tensile Socket Head Cap Screws
2 T Joining Plate (Aluminum) (Optional)
2 T Joining Plate (Acrylic) (Optional)
4 Double T-Nut
2 Triple T-Nut
X and Y V-Slot
2 V-Slot 20x20 Linear Rail Silver (59cm) (Optional)
1 V-Slot 20x20 Linear Rail Silver (55cm) (Optional)
2 V-Slot 20x20 Linear Rail Black (59cm) (Optional)
1 V-Slot 20x20 Linear Rail Black (55cm) (Optional)
3D Printer 4 Legs Kit
4 stick Anti Vibration for 3D Printers and other machines 40mm
4 M8 Hex Furniture Nut For Wood
4 Screw leveling legs
J3030 Acrylic Or Aluminum Kit
2 X Axis Right side plates (Aluminum) (Optional)
2 X Axis Right side plates (Acrylic) (Optional)
2 X Axis Left side plate (Aluminum) (Optional)
2 X Axis Left side plate (Acrylic) (Optional)
1 X Axis Gantry Plate (Aluminum) (Optional)
1 X Axis Gantry Plate (Acrylic) (Optional)
1 X Axis Limit switch mount Plate (Aluminum) (Optional)
1 X Axis Limit switch mount Plate (Acrylic) (Optional)
1 Y Axis Build Plate 32cmx32cm (Aluminum)
1 Y Axis Belt Tension and idler mount (Aluminum) (Optional)
1 Y Axis Belt Tension and idler mount (Acrylic) (Optional)
1 Y Axis Motor mount (Aluminum) (Optional)
1 Y Axis Motor mount (Acrylic) (Optional)
1 Y Axis Limit switch mount Plate (Aluminum) (Optional)
1 Y Axis Limit switch mount Plate (Acrylic) (Optional)
1 Z Axis Top Plate (Acrylic)
1 Z Motor spacer (Aluminum) (Optional)
1 Z Motor spacer (Acrylic) (Optional)
1 Z Axis optical limit switch mount Plate (Aluminum) (Optional)
1 Z Axis optical limit switch mount Plate (Acrylic) (Optional)
Idler, Pulley and Belt
2 GT2 40 Tooth 8mm Bore Timing Belt Pulley
3 GT2 20 Tooth 5mm Bore Timing Belt Pulley
2 Aluminum Idler Pulley 5mm
2 Rubber Timing Belt Width 6mm
1 Gt2 6mm Closed Loop Timing Belt 2Gt-6(930mm)
Bearing, V-Wheel
17 Xtreme or Solid V Wheel Kit
4 693zz Bearing 3x8x4 Flanged
4 688z Bearing 8x16x5 Flanged
Screws and Nut
9 Eccentric Spacer 6mm
17 Aluminum Spacer 5.1 x 10 x 6mm
2 Lead Screw 40cmx8mm
2 Nut Block for 8mm Metric Acme Lead Screw
7 Double T-Nut
6 Slide t-nut 5mm
27 M5 Nylock Nut-100-551
2 Lock Collar 8mm
8 Low Profile Screws M5X10MM
4 Low Profile Screws M5X20MM
2 Low Profile Screws M5X25MM
3 Low Profile Screws M5X30MM
8 Low Profile Screws M5 X 35MM
6 Low Profile Screws M5 X 40MM
6 M5x15mm High Tensile Socket Head Cap Screws
2 M3x30mm High Tensile Socket Countersunk Screws
15 M3x10mm High Tensile Socket Head Screws
10 M3x15mm High Tensile Socket Head Screws
10 M3x20mm High Tensile Socket Head Screws
10 M3x30mm High Tensile Socket Head Screws
25 Light Metal Nut Washer 3mm
25 Light Metal Nut Washer 5mm
25 Iron Nut 3mm
50 M2x8mm Bronze Philip Screw
Electronics
1 Arduino Mega 2560
1 Control Board Ramps Reprap 1.4
4 Stepper Motor Driver A4988 Module
2 Limit Switch (MS.2 - 19.5 x 10.0 x 6.0 mm)
1 Optical Endstop Optical Limit Switch
1 Smart LCD 128 x 64 With Controller & SD Card
1 DC 12V Air blower,5cm Turbo blower,Humidifier fan,speed 4600RPM
2 3D PRINTER EXTRUDER FAN 4X4 12V
1 Mosfet Module For Heatbed Power (Optional)
1 SSR-25DA (Solid State Relay 25A) Input 80-250Vdc / Output 24-380Vac (Optional)
Heatbed
1 NTC 3950 Thermistors-big head Size with dupont
1 PCB Heat Bed 12,24v 21.4x21.4 (Optional)
1 Silicone Heat Bed (300x300mm) 600W - 220V (Optional)
1 Print Surface For 3D Printer 300x300mm - 3mm
8 M3 Copper Spacer 14mm F/F
16 M3x6mm Phillips Flat Head Machine Screws
Hotend
1 E3D V6 Long distance J-head Hotend with Cooling fan, heater, thermistor and fan duct built-in for 1.75mm 3D Printer Nozzle 0.4mm
Extruder
1- MK8 All-Metal Remote Extruder for 1.75mm 3d Printer Parts
Motors
4 Nema 17 Used motors (Optional)
4 Motor NEMA17 48mm New (Optional)
Power Supply
1 SMPS Power supply 12V (Optional)
1 SMPS Power supply 24V + Step down (Optional)
Control Box
1 Plywood Control Box (Optional)
1 Acrylic Control Box (Optional)
10 Aluminum legs 20x40 Length 80mm
1 AC POWER CONNECTOR WITH FUSE HOLDER
1 SW2 ON/OFF (Up to 8A 250V AC) 2Pin
1 USB 2.0 Type B Male To Female
1 Power Cable
Cables
4 4PIN To 6PIN 1m Long Cable For Nema 17 Motor
1 Extension Sensors Cable 70cm
4 4PIN To 6PIN 1m Long Cable For Nema 17 Motor (Without Soket)
1 15A HeatBed High Power Output Cable
1 Meter PTFE Teflon Tube Remote Nozzle feed Guide 2 x 4
1 Arduino Mega USB Cable
Printed Parts
1 Hotend Mount with Auto Bed Leveling System With Optical Limit Switch
1 LCD Cover
2 LCD Cover Mount
1 X Axis Right Movement Blocker
Others
1 Cable Drag Chain 7x7
1 Cable Drag Chain 15x15
Special Spool holder
1 Special Spool Holder Acrylic 10mm
1 Metal Threaded Bar 8mm Length 20cm
2 Filament Roll Spool With 2 608 RS Bearing
