Main Materials: Aluminum,Acrylic
Main Color: Silver
Working Area: 20x20x20
Contents:
Aluminum 3D Printer Frame Kit(37.5x41.5x41.5)
7 V-Slot 20x20 Linear Rail (37.5cm)
8 M5x35mm High Tensile Socket Head Screws
10 M5x10mm High Tensile Socket Head Cap Screws
2 T Joining Plate (Acrylic)
2 Double T-Nut
2 Triple T-Nut
4 Legs Kit
4 Screw leveling legs
4 M8 square nut
4 stick Anti Vibration 40mm
X,Y and Z smooth rod
2 Smooth Rod 304 Stainless Steel 8mm (37.5cm)
2 Smooth Rod 304 Stainless Steel 8mm (40cm)
2 Smooth Rod 304 Stainless Steel 8mm (39cm)
J2020ps Acrylic Kit
1 Y Base Bulid Plate 37.5cmx41.5cm
1 Y Axis Bulid Plate 22cmx22cm
1 Y Axis Belt Tension and ideler mounte
1 Y Axis Motor mount
2 Z Axis Top Plate
2 Z Axis button Plate
Printed Parts
1 X Axis Right side
1 X Axis Left side
1 X Axis Gantry
1 X Axis Limit switch mount
1 Y Axis Limit switch mount
1 Hotend Mount With Auto Bed Leveling System
2 T8 Printed Nut For Lead Screw
Idler,Pulley and Belt
1 GT2 60 Tooth 8mm Bore Pulley
6 GT2 20 Tooth 5mm Bore Pulley
4 Aluminum Idler Pulley 5mm
2 Timing Belt 6mm
1 Closed Timing Belt 6mm (930mm)
1 Closed Timing Belt 6mm (320mm)
bearing,V-Wheel
10 Linear Bearing 8mm - LM8UU
2 F623zz bearing 3x6x4
2 608zz bearing 8x22x5
4 F688z Flanged Bearing 8x16x5
Screws and Nut
2 Lead Screw 40cmx8mm
20 Double T-Nut
6 M5 Slide t-nut
2 Lock Collar 8mm
20 Low Profile M5x10
50 M3 Screws M3x10
50 Light Metal Nut Washer 3mm
50 Iron Nut 3mm
Elctronics
1 Arduino Mega 2560
1 Ramps 1.4
4 A4988 – Stepper Motor Driver ( Optional )
4 DRV-8825 Stepper Motor Driver for Arduino ( Optional )
2 Limit Switch (MS.1 – 12.8 x 5.7 x 5.4mm)
1 Smart LCD 128 x 64 With Controller & SD Card
1 5015 Radial Turbo Blower DC Fan 12Vdc
2 12vdc fan 40x40
Heatbed
1 NTC 3950 Thermistors-big head Size with dupont
1 3D Printer PCB Mk2b 12/24 Volt Heatbed
1 Print Surface For 3D Printer 220x220mm - 3mm
4 M3 Copper Spacer 14mm F/F
Hotend
1- J-head V6 HotEnd Full Kit 1.75mm – 0.4mm Nozzles
Extruder
1- MK8 All-Metal Remote Extruder for 1.75mm 3d Printer Parts
Motors
4 Nema 17 Used motors( Optional )
4 Motor NEMA17 48mm New ( Optional )
Power Supply
1 12Vdc/30A Power supply
Control Box
1 Plywood Control Box ( Optional )
1 Acrylic Control Box ( Optional )
6 V-slot 20x40 Aluminum legs 80 mm
1 SW2 ON/OFF (Up to 8A 250V AC) 2Pin
1 AC POWER CONNECTOR WITH FUSE HOLDER
cables
1 Arduino Mega USB Cable
1 15A HeatBed High Power Output Cable 100cm
1 USB 2.0 Type B Male To Female 1500MM
