Sorry - this product is no longer available

Nema 23 Stepper Motor 23HS5628

23HS5628 Nema23 Stepper Motor Model: 23HS5628 Shaft Diameter: 8mm Step Angle: 1.8? Motor Length: 56mm Rated Current: 2.5A Phase Resistance: 0.9 ohms Phase Inductance: 2.5mH Holding Torque: 12.6Kg.cm Lead Wire: No.4 Motor Wire: The default length is 30cm

Be the first to review this product

Availability: Out of stock

SKU: 08.13.03

850.00 ج.م.‏

Qty:

23HS5628 Nema23 Stepper Motor

Model: 23HS5628
Shaft Diameter: 8mm
Step Angle: 1.8?
Motor Length: 56mm
Rated Current: 2.5A
Phase Resistance: 0.9 ohms
Phase Inductance: 2.5mH
Holding Torque: 12.6Kg.cm
Lead Wire: No.4
Motor Wire: The default length is 30cm

Features:

Widely used in 3D printers, surveillance equipment, medical / textile / packaging machinery and stage lighting, etc.
The motor wire is made of pure copper, with uniform copper wire layout and corrosion resistance.
The motor adopt 4 pin cable outlet method, easy to connect.
Made of high-quality materials, durable and long service.
Available in two shaft diameter for choice:? 8mm.

Package Includes:

1 x Nema23 Stepper Motor
1 x Cable
