Get your ACRO system together quickly and easily with the included 11-piece plate set. Use these plates on your own design or as replacement parts for your ACRO System.
\(2) Y Axis Plate [FRONT]
(2) Y Axis Plate [REAR]
(1) Y Axis Plate [LEFT]
(1) Y Axis Plate [RIGHT]
(2) X Axis Plate [FRONT]
(1) X Axis Plate [REAR]
(2) X Axis Spacer
Thickness: 6mm (1/4")
These heavy duty Cross Joining Plates are perfect for any project requiring connection strength.
These Plates can be mounted to V-Slot Linear Rail using 10mm Low Profile Screws and Tee Nuts.
6105 - T5 Plate
100mm x 60mm
M5 Diameter Screw Holes, 20mm Spacing
Clear Anodized Aluminum
This NEMA 17 Motor Mount Plate is designed to easily allow for the modular connection of a NEMA 17 Stepper Motor.
"You can also combine this plate with the V-Slot Gantry Plate to make a great Belt and Pinion System!"
Version - V1
6063 - T6 Plate
Matrial : Steel
Use this Reduction/Stand Off Plate in conjunction with the Parts listed below to create a nice, clean hidden stepper motor one to one ratio.
"This plate is great for hiding the Stepper Motor or moving it out of the way on your design!"
THIS UNIVERSAL BUILD PLATE IS VERY MODULAR AND CAN ADAPT TO MOST ALL BUILD CONFIGURATIONS.
THE IDEA BEHIND THIS PLATE IS TO GIVE YOU A STRONG, STABLE UNIVERSAL MOUNTING PLATFORM FOR YOUR HEATED BUILD PLATES BUT CAN ALSO BE USED FOR MANY OTHER APPLICATIONS WHERE A LARGER PLATE IS NECESSARY.
THIS NEMA 23 MOTOR MOUNT PLATE IS DESIGNED TO EASILY ALLOW FOR THE MODULAR CONNECTION OF A NEMA 23 STEPPER MOTOR. YOU CAN ALSO COMBINE THIS PLATE WITH THE V-SLOT GANTRY PLATE TO MAKE A GREAT BELT AND PINION SYSTEM!
Interchangeable mount allows for easy attachment of a motor to C-Beam Linear Rail. Includes bearing recess typically used in lead screw transmission. Additional countersunk holes for flush mounts make this plate a great choice for your project.
C-Beam Linear Rail compatible
What is Included
(1) C-Beam End Mount
Size: 80 x 50mm
Finish: Brushed and Anodized
Professionally designed with time saving features. Easy to mount with 5 pre-threaded M5 mounting holes. Belt loop notches for quick connection of timing belt. Two oversized recessed holes for flush mounting and adjusting eccentric spacers. Quick orientation with secondary holes designated to lock wheels when attaching your V-Slot Linear Rail.
The V-Slot Spacer Blocks were designed to be used in conjunction with the V-Slot Gantry Plate. "This Spacer Block allows you to raise the V-Slot Gantry Plate up away from the rail 12mm, so that you can run transmission components, such as a Belt Drive or Threaded Rod underneath the V-Slot Gantry Plate." Product Details Qty. 1 M5 Tapped Holes to allow mounting to the V-Slot Gantry Plate 3 Holes that allow for mounting of full size OpenBuilds Wheels Anodized Aluminum Color: Black OpenBuilds Part CAD Models and Drawings Brand : OpenBuilds Type : 3D Printer Accessories
